ยี่ห้อ:FAITHFUL
รุ่น:DGF-4AB DGF-5AB DGF-6AB DGF-7ABDGF-8AB
Big Forced Air Drying Oven ตู้อบลมร้อนขนาดใหญ่ แบบมีพัดลม ยี่ห้อ FAITHFUL ตู้อบแห้งอุตสาหกรรมขนาดใหญ่ ความแม่นยำสูง ออกแบบมาเพื่อตอบสนองความต้องการ
DGF-4AB / DGF-5AB ควบคุมอุณหภูมิที่ Temp Range RT+10-250℃
DGF-6AB / DGF-7AB/ DGF-8AB ควบคุมอุณหภูมิที่ Temp Range RT+10-300℃
Big Forced Oven ตู้อบลมร้อนขนาดใหญ่ แบบมีพัดลม ยี่ห้อ FAITHFUL รุ่น DGF-4AB, DGF-5AB, DGF-6AB, DGF-7AB
DGF-8AB
| Model | DGF-4AB | DGF-5AB | DGF-6AB | DGF-7AB | DGF-8AB |
|---|---|---|---|---|---|
| Cycle Mode | Fan – forced air circulation | ||||
| Temp. Range | RT+10~250°C | RT+10~300°C | |||
| Temp. Resolution Ratio | 0.1°C | ||||
| Temp. Motion | ±1°C | ||||
| Temp. Uniformity | ±3% | ||||
| Inner Chamber | Stainless steel inner chamber | ||||
| Outer Shell | Galvanized sheet electrostatic spraying exterior | ||||
| Insulation Layer | High quality rock wool board (with CE) | ||||
| Heater | Stainless steel heating tube | ||||
| Power Rating | 6kW | 6.6kW | 9kW | 12kW | 15kW |
| Exhaust Hole | On top or side | ||||
| Temp. Control Mode | PID intelligent control or Multi-segment programmable (optional) | ||||
| Temp. Setting Mode | Touch button setting | ||||
| Temp. Display Mode | LCD Digital Display | ||||
| Timer | 0~9999min (with timing wait function) | ||||
| Operation Function | Fixed temperature operation, timing function, auto stop | ||||
| Additional Function | Temperature deviation correction, menu locked, power-off memory | ||||
| Sensor | PT100 | ||||
| Safety Device | One key to start overheat power off | ||||
| Volume | 640L | 1000L | 1300L | 1870L | 3070L |
| Max Shelf Number | 11 | 11 | 11 | 11 | 12 |
| Load Per Rack | 30kg | ||||
| Shelf Space | 70mm / 100mm | ||||
| Power Supply | 380V | ||||
| N.W/G.W (kg) | 200 | 260 | 350 | 480 | 800 |
| Shelf | 2 | ||||
| Shelf Frame | No | ||||
| Optional Accessories | Spare shelf, Program controller, RS485 interface, Printer | ||||
