| Max. Capacity |
50 g |
40 g |
50 g |
120 g |
200 g |
| Readability (Weight) |
0.1 mg |
1 mg |
1 mg |
1 mg |
1 mg |
| Readability Moisture |
0.0001% |
0.001% |
0.001% |
0.001% |
0.001% |
| Repeatability (Sample 2g) (sd) |
0.05% |
0.1% |
0.1% |
0.1% |
0.1% |
| Repeatability (Sample 10g) (sd) |
0.02% |
0.03% |
0.03% |
0.03% |
0.03% |
| Units of Measurements |
%M, %D, %R (ratio), Gm/Lt, %M Atro, %D Atro |
| Statistics |
Method wise statistics – 100 samples using 40 methods or
Batch wise for each individual 100 batches for last 999 results |
| Technology |
Infra RED Halogen |
| Temperature Range |
Max. to 175°C (Optional to 250°C) |
| Temperature Increment |
Interval 1°C |
| Heating Profile |
Standard, Gentle, Rapid, Steps, High Temperature |
| Switch off Criteria |
Auto, Manual, User Def Weight / Time, User Def % unit / Time, Intelligent |
| Auto Method Development |
Intelligent |
| Method Memory |
40 |
| Batch Memory |
100 |
| Method designation |
Alpha Numeric |
| Serial Number |
Yes |
| Compile |
Yes (Method Linking) |
| Operating Temperature |
15°C to 35°C |
| Display |
Graphical LCD Display with LED backlight |
| Data Interface |
RS 232C Bidirectional, USB, Ethernet, Ps2 |
| Print |
GLP / GMP Compliant, User Configurable |
| Password |
Method, Setting, Print Format, Data Delete, Calibration, Drying |
| Power Supply |
230V / 50Hz or 115V / 60Hz |
| Power Consumption (Watt) |
Max 415 |
| Housing Dimension (mm) |
211 (W) x 342 (D) x 187 (H) |
| Net Wt. / Grps Wt. |
5 Kg / 8 kg |
| Packing Dimension (mm) (W x D x H) |
325 x 390 x 285 |
